Z-محور LWZ4090 40*90 مللي متر تتوافق الشريحة ناقل الحركة اليدوي مقبض عالي الدقة in Saudi Arabia Z-محور LWZ4090 40*90 مللي متر تتوافق الشريحة ناقل الحركة اليدوي مقبض عالي الدقة in Saudi Arabia

Z-محور LWZ4090 40*90 مللي متر تتوافق الشريحة ناقل الحركة اليدوي مقبض عالي الدقة

SAR 1,336
ماركة
IPDBLBYL
وزن
50 g
– 1 +

مميزات خاصة

  • Roller Tables
  • High parallelism and repeatability: Achieve ≤ 0.3mm/60mm parallelism and 0.1mm minimum scale for reliable and repeatable movement.
  • Aluminum Alloy Construction: Made of lightweight aluminum alloy, ideal for integration with other devices.
  • Large stroke and high load capacity: With a stroke of ±30mm and a load capacity of 49N, it is suitable for heavy-load tasks.
  • Rack and Pinion Drive: A rack and pinion drive is used to provide fast motion and large strokes for dynamic applications.
  • Dovetail Z-axis | Dovetail slider Z-axis | High-precision knob fine-tuning: Use high-precision knobs for fine-tuning to ensure smooth and accurate positioning.

وصف

Roller Tables
scope:
1. Workbench size: 40*90mm
2.Moving direction: Z axis
3. Driving method: Micrometer head
4. Stroke: ±30mm
5. Load: 49N (5kgf)
6.Moving parallelism: 0.3mm/60mm
7. Minimum scale: 0.1mm
8. Weight: 0.46KG
