Product overview:
Transformer DC Winding Resistance Tester is a measurement project for the inspection, installation, debugging, and preventive testing of semi-hed and hed products in transformer manufacturing. It can effectively detect hidden dangers after manufacturing and operation of defects such as material selection, welding, loose connection parts, short circuits, and fractures in transformer coils. To meet the needs of rapid measurement of transformer DC resistance, a new generation CT series DC resistance tester has been developed. The resistance tester is controlled by a microcontroller and automatically performs functions such as self inspection, data processing, display, storage, and printing.

Technical parameters:
1. Working power supply: built-in 12.6V/7.8AH lithium battery
2. Output current: 5mA, 100mA, 300mA, 1A, 5A, 10A, automatic
3. Measuring range: 0-20k
4. Accuracy: ±(0.2% RD+0.05% FS)
5. Printer: micro printer
6. Minimum resolution: 1u
7. Display: large screen color LCD

Model
JH2510-B
Output current
5mA, 100mA, 300mA, 1A, 5A, 10A, automatic
Measuring range
0-20k
Minimum resolution
1u
Weight
4kg
Accuracy
±(0.2% RD+0.05% FS)
Display
Large screen color LCD
