General information
Type CPU / Microprocessor
Market segment Desktop
Model number ? FX-6300
CPU part numbers
FD6300WMW6KHK is an OEM/tray microprocessor
FD6300WMHKBOX is a boxed microprocessor with fan and heatsink
Frequency ? 3500 MHz
Maximum turbo frequency 4100 MHz
Boosted P states [1] #1: 4100 MHz, 1.425V
#2: 3800 MHz, 1.4125V
Bus speed ? One 2600 MHz 16-bit HyperTransport link
Package 940-pin organic micro Pin Grid Array (UOC940)
Pb-free
Socket Socket AM3+
Weight [1] 1.3oz / 38.1g (CPU)
Fan/heatsink Z7MH01T001
Architecture / Microarchitecture
Microarchitecture Piledriver
Platform Volan
Processor c ? Vishera
c stepping ? OR-C0
CPUID 600F20
Manufacturing process 0.032 micron
Data width 64 bit
The number of CPU cores 6
The number of threads 6
Floating Point Unit Integrated
Level 1 cache size ? 3 x 64 KB 2-way set associative shared instruction caches
6 x 16 KB 4-way set associative data caches
Level 2 cache size ? 3 x 2 MB 16-way set associative shared exclusive caches
Level 3 cache size 8 MB 64-way set associative shared cache
Multiprocessing Uniprocessor
Extensions and Technologies
MMX instructions
Extensions to MMX
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
SSE4a ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
BMI1 / Bit Manipulation instructions 1
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
FMA4 / 4-operand Fused Multiply-Add instructions
TBM / Trailing Bit Manipulation instructions
XOP / eXtended Operations instructions
AMD64 / A 64-bit technology ?
AMD-V / A Virtualization technology
Turbo c 3.0 technology
Security Features
EVP / Enhanced a Protection ?
Low power features
PowerNow!
Low power P states [1] #1: 3000 MHz, 1.225V
#2: 2500 MHz, 1.125V
#3: 2000 MHz, 1.025V
#4: 1400 MHz, 0.9V
Integrated peripherals / components
Integrated graphics None
Memory controller The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1866
Maximum memory bandwidth (GB/s): 29.9
Other peripherals
HyperTransport technology ?
Electrical / Thermal parameters
Maximum operating temperature ? 70.5°C
Thermal Design Power ? 95 Watt
