c 2 Quad Q9000 specifications
The specs can be used for short-term
listings on auction and classifieds sites
General information
Type CPU / Microprocessor
Market segment Mobile
Family I c 2 Quad Mobile
Model number ? Q9000
CPU part numbers AW80581GH0416M is an OEM/tray microprocessor
BX80581Q9000 is a boxed microprocessor without fan and heatsink
Frequency ? 2000 MHz
Bus speed ? 1066 MHz
Clock multiplier ? 7.5
Package 478-pin micro-FCPGA
1.38" x 1.38" (3.5 cm x 3.5 cm)
S-spec numbers
Part number ES/QS processors Production processors
QJTA SLGEJ
AW80581GH0416M + +
BX80581Q9000 +
Architecture / Microarchitecture
Microarchitecture c
Platform Montevina
MontevinaPlus
Processor c ? Penryn
c stepping ? E0 (SLGEJ)
CPUID 1067A (SLGEJ)
Manufacturing process 0.045 micron
Data width 64 bit
The number of CPU cores 4
The number of threads 4
Floating Point Unit Integrated
Level 1 cache size ? 4 x 32 KB 8-way set associative instruction caches
4 x 32 KB 8-way set associative write-back data caches
Level 2 cache size ? Shared 2 x 3 MB 12-way set associative caches
Multiprocessing Uniprocessor
Extensions and Technologies MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4.1 / Streaming SIMD Extensions 4.1 ?
EM64T / Extended Memory 64 technology / I 64 ?
NX / XD / Execute disable bit ?
VT / Virtualization technology ?
Dual Dynamic Acceleration ?
Low power features C1/AutoHALT, C1/MWAIT, C2, C3 and C4 c states
Stop Grant mode ?
Sleep mode ?
Deep Sleep mode ?
Deeper Sleep mode ?
FSB low-power enhancements
Enhanced / technology ?
Integrated peripherals / components
Integrated graphics None
Electrical / Thermal parameters
V c ? 0.9V - 1.25V
Minimum/Maximum operating temperature ? 0°C - 100°C
Minimum/Maximum power dissipation ? 16.54 Watt (Deeper Sleep mode) / 74.35 Watt
Thermal Design Power ? 45 Watt
Notes on I c 2 Quad Q9000
Bus frequency is 266 MHz. Because the processor uses Quad Data Rate bus the effective bus speed is 1066 MHz
Processor operates at 0.85 Volt - 1.1 Volt in Low Frequency mode
