c i5-3230M (PGA) specifications
The specs can be used for short-term
listings on auction and classifieds sites
General information
Type CPU / Microprocessor
Market segment Mobile
Family I c i5 Mobile
Model number ? i5-3230M
CPU part number AW8063801208001 is an OEM/tray microprocessor
Frequency ? 2600 MHz
Maximum turbo frequency 3200 MHz (1 c)
3000 MHz (2 cores)
Bus speed ? 5 GT/s
Clock multiplier ? 26
Package 988-pin micro-PGA (rPGA988B)
Socket Socket G2 / rPGA988B
S-spec numbers
Part number ES/QS processors Production processors
QD6E SR0WY
AW8063801208001 + +
Architecture / Microarchitecture
Microarchitecture Ivy Bridge
Processor c ? Ivy Bridge
c steppings ? E1 (QD6E)
L1 (SR0WY)
CPUID 306A9 (QD6E, SR0WY)
Manufacturing process 0.022 micron
Data width 64 bit
The number of CPU cores 2
The number of threads 4
Floating Point Unit Integrated
Level 1 cache size ? 2 x 32 KB 8-way set associative instruction caches
2 x 32 KB 8-way set associative data caches
Level 2 cache size ? 2 x 256 KB 8-way set associative caches
Level 3 cache size 3 MB 12-way set associative shared cache
Physical memory 32 GB
Multiprocessing Not supported
Features MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
F16C / 16-bit Floating-Point conversion instructions
EM64T / Extended Memory 64 technology / I 64 ?
NX / XD / Execute disable bit ?
HT / Hyper-Threading technology ?
TBT 2.0 / Turbo Boost technology 2.0 ?
VT-x / Virtualization technology ?
VT-d / Virtualization for directed I/O
Low power features Enhanced / technology ?
Integrated peripherals / components
Integrated graphics GPU Type: HD 4000
Graphics tier: GT2
Microarchitecture: Gen 7
Execution units: 16
Base frequency (MHz): 650
Maximum frequency (MHz): 1100
The number of supported displays: 3
Memory controller The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1333, DDR3-1600, DDR3L-1333, DDR3L-1600, DDR3L-RS 1333, DDR3L-RS 1600
Maximum memory bandwidth (GB/s): 25.6
Other peripherals Direct Media Interface 2.0
PCI Express 3.0 interface
