Specifications:
Product series: auto relay
Contact load: high power
Contact switching current: 500A
Contact switching voltage: 7.8VDC
Contact form: transformation type
Rated current: 500A
Protective features: sealing type
Coil power: 12V DC, 24V DC
Weight: 235g
CONTACT DATA
Contact material
AgSn0_27In_20_33
Contact form
1H(1A)
Contact Ratings
500A
Contact Resistance
100mMax at 6VDC 1 A
Max Switching Current
500A
Max Switching Voltage
14VDC
Max Switching Power
500A
Life Expectancy Electrical
100,000 Operations(at 30 Operations/minute)
Life Expectancy Mechanic
10,000,000 Operations
COIL SPECIFICATION
Nominal Voltage (VDC)
Coil Resistance()
Max Operate Voltage (VDC)
Mix Release Voltage (VDC)
Max Applicable Voltage (VDC)
12
16
8 1.2
14
9
CHARACTERISTICS:
Temperature Range
-30~80°
Vibration Resistance
10-55Hz,1.5mm
Shock Resistance Operations Extremes
Damage Limits
50g
100g
Humidity
40-85%
Insulation Resistance
100m min at 500vdc
Safety Standard
Dielectric Strength Between Open Contacts
2000VAC(for 1 minuter/s)
Between Contacts and coil
1500VAC(for 1 minuter/s)
Operate Time
50ms
Release Time
50ms
Package Included:
1 x Heavy current relay
==========
Hign-concerned Chemical : None
Power Source : DC
Theory : Electromagnetic Relay
Protect Feature : Sealed
is_customized : Yes
Usage : General Purpose
Contact Load : High Power
Model Number : Start Relay 500A
Voltage : 12V
Contact switching current : 500A
Coil power : 12V DC,24V DC
