Plugs
Specification: MIL-DTL-26482
Sealing: Sealed
Shielding: Yes
Connector Type: Circular
Connector Style: Plug
Mounting Type: Cable
Orientation: Straight
Endbell Type: Grommet Nut
Number of Contacts: 4
Contact Style: Socket
Termination Method: Solder
Insert Arrangement: 8-4
Contact Size: 4#20
Contacts Supplied: Yes
Contact Material: Copper Alloy
Contact Plating: Gold
Shell Material: Aluminum Alloy
Shell Plating: Olive Drab Chromate over Cadmium
Shell Color: Olive Drab
Insert Material: Neoprene
Grommet Seal Material: Neoprene
Amperage Rating: 13A
Operating Voltage DC: 850
Operating Voltage AC: 600
Operating Temperature: -67 to +257 (-55 to +125)
Contact Mating life: 500
RoHS: No
Insert Rotation Keying: Normal
