Transducers
Inductors
Technical Parameters
power supply
power supply
DC12V DC15V DC24V
customizable
enter
input signal
AC 0～1600A customizable
Output
output signal
4-20mA 0-20mA 0-5V 0-10V customizable
Other parameters
Available aperture
20mm 38mm 50mm 75mm 80mm
accuracy
0.5% full scale
Response time
Linearity
0.5% full scale
Temperature drift
500PPM/
bandwidth
DC~20KHz
Current consumption
25 mA
Isolation withstand voltage
2.5k/50Hz 1 minute
Offset voltage
20 mV
Zero output
0.15mA
Di/Dit attention
>50A/μs
working environment
-10~+70
Storage environment
-25~+85
