A capacitor is an electrical component that temporarily stores an electrical charge and is a key component for starting electric motors.

Low Dissipation: Minimizes energy losses, improving efficiency

High Insulation Resistance: Ensures safe and reliable operation

Good Self-Healing Ability: Extends the life of the capacitor

Resistance to Surge Currents: Withstands current peaks without being damaged

Stable Electrical Performance: Maintains constant performance under various conditions

Internal Explosion Proof Device: Provides additional protection for greater safety

Specifications:

- Construction: Round, durable metal casing, 3 terminals, 12 connection pins with red, white and black plastic protectors.
- Color: Metalic
- Size range: 35 + 5 μF
- Supplier code: A195-CAN
- Shape: Round
- Rated voltage: 370/440 VAC
- Rated frequency: 50/60 Hz
- Tangent of loss angle: 0.0035 a 1KHz
- Voltage between poles: 2Vn 60s
- Polar shell withstand voltage: 2000V 60s
- Insulation resistance: RC≥3000M Ω a 25°C

Certifications: CE, CQC 10006047040, GB/T 3667.1/IEC 60252-1

Applications: Industrial electric motors, compressors, air conditioners

Dimensions:
- Diameter: 2 inch.
- High: 4 1/8 inch.
- Betbetween terminals: 13/16 inch.
