UCFL205 Premium 2 Bolt Flange Bearing 25 mm Bore in Saudi Arabia

UCFL205 (25mm) Bore 2-Bolt Square Flange Bearing Unit, Self-Aligning Mounted Bearing, Cast Iron Housing, Set Screw Lock

SAR 95
– 1 +

Special Features

  • Housing Material Cast Iron / Bearing Insert Material Alloy Steel 52100
  • Type: 2-Bolt flange units with set screw lock./Self Aligning flange units Bearings
  • This mounted bearing has a wide number of applications and is used in Agriculture, Automotive, Pump, Construction, Manufacturing Equipment, Conveyor, Fan Assemblies, Farm Machinery, and Feed Mill
  • These general-purpose pillow block ball bearings are suitable for environments where corrosion is not a concern. They are often used in material handling, packaging, and dry-goods processing.
  • Country of origin: Made in China.

Description

Manufacturer Part Number - UCFL205-25MM
Bearing Insert Type - Radial Ball
Number of Mount Holes - 2
Housing Material - Cast Iron
Housing Material Finish - Painted
Bearing Insert Material - Alloy Steel
Bearing Material Grade - 52100
Shaft Locking Type - Set Screws
Bore Diameter - 25 mm
Overall Length – 35.7 mm
Overall Width – 68.2 mm
Overall Height – 130.1 mm
Flange Thickness – 12.7 mm
Mount Hole Center-to-Center Length – 98.8 mm
Mounting Bolt Size - M10
Mount Hole Size – 11.1 mm
Closure - Double Sealed
Seal Material - Rubber
Lubrication Openings - One Zirc Fitting
Rolling Element Rows - 1
Bore Type - Cylindrical
Housing Type - Square
Maximum Temperature - 120 °F
Minimum Temperature – (-40) °F
Static Radial Load Capacity – 7,850 N
Dynamic Load Capacity - 14,000 N
Features - Anti-Rotation Device; Cast-Iron Housing; Dual Heavy-Duty Slinger Type Contact Seals; Standard Duty Square Flange Unit, Set Screw Locking; Triple Lip Seals (R3 Suffix) Optional; Wide Inner Ring Bearing
