Vacuum Gauges
Maximum overvoltage: 10KPA
Measuring range:930.8020-200PA
930.8130-300PA
930.82 40-400PA
930.8350-500PA
930.85 200-1000PA
930.86500-2500PA
930.871000-4000PA
Working temperature: -30°C~85°C (overvoltage resistance 5000PA);
Pressure connection: 6.2MM diameter hose (also equipped with installation accessories)
Medium: Air, non-flammable and non-corrosive
Gas output: SPDT suitable medium: air, non-corrosive gas.
Contact capacity: 1.5A@250VAC
Range setting: The setting in the range cover can be adjusted on site
Shell material: reinforced fiberglass material, cover is plastic
Overall dimensions: 81x53MM;
