Transformers
Specification:
Power: 30VA
Primary input voltage: AC0-230V AC0-115V 50/60Hz optional
The primary is wound with 0.27mm wire diameter temperature-resistant 220-degree 6N oxygen-free copper OFC enameled wire, which is enough to meet the 40W output requirement, and the DC internal resistance is as low as 36R, which is lower than all 50W toroidal transformers.
Secondary output voltage can be
The secondary is 1 flat/3A, using the same material as the primary, and the temperature resistance is 220 degrees. The 6N oxygen-free copper OFC enameled wire is wound by hand, and the wire is extremely evenly close to the iron core.
Adjustment rate: 10%
Size: 85*30mm (±3mm) can be potted with 90*50mm bull cover (additional 30 yuan for each)
Weight: 0.6Kg
Supporting high-quality installation accessories, including top pressure plate, soft gasket, stainless steel gong wire, gong mother, and meson.
