Bearing Insert Type Radial Ball
Bearing Insert Material Alloy Steel
Bearing Material Grade 52100
Shaft Locking Type Set Screws
Bore Diameter 3/4 in
Bore Diameter Tolerance +/- 0.0007 in
Bore Type Cylindrical
Mount Type Bolt-Through
Number of Mount Holes 2
Mounting Surface to Shaft Center Height 1.312 in
Mount Hole Center-to-Center Length 2 in
Mounting Bolt Size M10
Expansion Type Fixed
Housing Material Cast Iron
Housing Material Finish Painted
Overall Length 2.559 in
Overall Width 1.22 in
Overall Height 2.519 in
Base Height 0.57 in
Base Width 1.259 in
Static Radial Load Capacity 1,494.98 lbf
Dynamic Radial Load Capacity 2,877.55 lbf
Closure Double Sealed
Seal Type Contact
Seal Material Synthetic Rubber
Lubrication Openings Grease Fitting
Lubricant Material Grease
Maximum Temperature 250 °F
Minimum Temperature -40 °F
Features Anti-Rotation Device; Dual Heavy-Duty Slinger Type Contact Seals; Grease Fitting for Adding Lubricant; One-Piece Cast Iron Housing, Solid Base; Standard Duty Unit, Eccentric Locking Collar; Triple Lip Seals Available on Request; Wide Inner Ring Bearing
