PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia PINTECH High Voltage Differential Probe, 100MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008B in Saudi Arabia

PINTECH High Voltage Differential Probe, 50MHz, 800V, 100X/10X Attenuation, with Standard BNC Interface, Oscilloscope Probe Kit Accessory N1008A

SAR 2,383
Brand
PINTECH
ModelN1008A
– 1 +

Special Features

  • Maximum differential test voltage: 800Vp-p, the N1008B probe is suitable for testing low voltages.
  • Accuracy (Typical)：±1%, Attenuation Ratio: 100X/1000X, Rise Time: 3.5ns. The professional active differential probe is small in size, easy to carry.
  • Bandwidth DC-100MHz (-3dB), featured with built-in auto-zero.
  • Widely Used: The oscilloscope probe features BNC interface, compatible with all oscilloscopes.
  • Package Included: N1008B differential probe host unit x 1, Adapter x 1, Probe Hook x 2, Manual x 1. PINTECH offers 1 Year warranty, you can contact us if you have any questions!

Description

MODEL: N1008B

Bandwidth (-3dB): DC-100MHz

Output(into 50kΩ load):＜7V

Offset(typical):＜±5mV

Attenuation Rate: 10X/100X

Rising Time: 3.5ns

Accuracy: ±1%

Input Impedance: Between the two ends: 4MΩ//1.25pF, Single-ended to ground: 2MΩ//2.5pF

Oscilloscope Input Impedance: 1MΩ

Weight: 284g/0.63lb

Dimension(LxWxH): 166.5x70.7x30 mm
