Mini capsule slip ring SNM012 6-wire/12-wire/18-wire slip ring 2A signal
parameter:
Speed: 150RPM or customized
Number of channels: 6 lines/2 lines/18 lines
Rated voltage: 240VAC/VDC
Rated current: 2A
Working temperature: -30℃~+80℃
Contact material:
Wire diameter: AWG30# silver-plated UL
Cable length: standard 150mm
Compressive strength: 300V 50Hz between two channels
Insulation resistance: 300M/300VDC
Dynamic resistance fluctuation value: minimum 10m
Shell material: engineering plastic
Working life: 5 million rpm (depends on working environment and speed)
