Description

Material: Plastic and Metal

Technical Parameters:

Withstand Voltage: Rotary Switch 250VAC, 1 Minute

Switching Rating: 24VDC, 25mA

Non-Switching Rating: 100mA, 50VDC

Contact Resistance: 100MΩ Max (Initial) (b) 200mΩ (After Final Test)

Insulation Resistance: 100MΩ Min, 250VDC

Operating Temperature Range: -25 C to 80 C

Solderability: 230 ±5 C 3± sec 75%

Electrical Life: 200mΩ Max, 20000 Steps

Electrical Rating: 13A-120V AC, 10(3)A-250V AC

Temperature(c): 105°C

Durability: 10000 Cycles

Quantity: 1PC

Note:

Due to manual measurement, please allow 1-2 Error of millimeters.

Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
