DB Electrical 300-12060 Armature Compatible With/Replacement For Delco 1881818, Lester 1865 Volt 6/12, Body OD 2.449", CE OD 0.500", DE OD 0.563" Tractors in Saudi Arabia

DB Electrical 300-12060 Armature Compatible With/Replacement For Delco 1881818, Lester 1865 Volt 6/12, Body OD 2.449", CE OD 0.500", DE OD 0.563" Tractors

SAR 450
Weight
2.2 kg
– 1 +

Special Features

  • Specs: Armature, Volt: 6/12, Rotation Direction: Clockwise, Body OD: 2.449"/62.200mm, CE OD: 0.500"/12.700mm, DE OD: 0.563"/14.300mm, Length: 12.220"/310.400 mm, CE to Stop: 20.700, DE to Stop: 174, LAM Stack Thickness: 2.512"/63.800mm, Notes Set Screw & Keyway on DE
  • Replaces OEM Numbers: Arrowhead: SDR3045, Delco: 1881818, J&N Electrical Products: 300-12060, 300-12060R, Lester: 1865
  • 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
  • 100% New Aftermarket Armature built to meet OEM specifications

Description

**Verify the part fits before purchasing**

Specs:

Description: Armature
Volt: 6/12
Rotation Direction: Clockwise
Body OD: 2.449"/62.200mm
CE OD: 0.500"/12.700mm
DE OD: 0.563"/14.300mm
Length: 12.220"/310.400 mm
CE to Stop: 20.700
DE to Stop: 174
LAM Stack Thickness: 2.512"/63.800mm
Notes Set Screw & Keyway on DE

Replaces OEM Numbers:

Arrowhead: SDR3045
Delco: 1881818
J&N Electrical Products: 300-12060, 300-12060R
Lester: 1865
