Li-ion/Lifepo4 /Lipo version
1、Balance start voltage: 3.0V-4.2V
2、Balance termination voltage: 2.9V (into undervoltage sleep state)
3、Maximum Balance current: The whole group error is 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)
4、3S quiescent current Full state: (4.2v*3cell) 12.6V 12mA
5、4S quiescent current Full state: (4.2v*4cell) 16.5V 15mA
6、7S quiescent current Full power state: (4.2v*7cell) 29.4V 15mA
7、8S quiescent current Full power state: (4.2v*7cell) 33.6V 14mA
8、Whether external power supply is required: no external power supply is required, and the internal energy transfer of the battery is used to transfer and the entire set batteries pack in balance .
9、Working environment temperature: 0-60 degrees

LTO version
1、Balance start voltage: 2.0V-2.8V
2、Balance termination voltage: 1.9V (into undervoltage sleep state) Maximum Balance current: The whole group error is 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)
3、5S LTO quiescent current Full state: 2.8v*5cell） 14V 12mA
4、6S LTO quiescent current Full state: 2.8v*6cell） 16.8V 15mA
5、Whether external power supply is required: no external power supply is required, and the internal energy transfer of the battery is used to transfer and the entire set batteries pack in balance .
6、Working environment temperature: 0-60 degrees
