Applications:
Household appliances
Transmission of Electrical Signals
lighting
medical equipment
communications and networking equipment
instrumentation
TV camera vedio speaker computer
Environmental Characteristics
Voltage Rating: 30V
Current Rating:0.5A
Contact Resistance Less 50M ohm
Insulation Resistance Over 100M ohm
Dielectric Withstanding: 1000V 50/60hz last for 1min
Withstand Voltage AV250V(50Hz)/Min
Electrical Life：Over 800000 times
Supply Voltage: -0.5 to 7.0V maximum.
Input Voltage: -0.5 to +0.5V maximum.
Operating Temperature: -20 deg. C to +70 deg. C maximum.
Storage Temperature: -30 deg. C to +80 deg. C maximum.
Soldering Temperature: 260 deg. C maximum.
Mechanical Characteristics
Installation angle : Straight/ Right Angle
Connector Mounting Type : Panel Mount/PCB Mount
Mechanical Life：Over 10000 times
Insertion Force: 5.9N minimum, 39.2N maximum.
Withdrawal Force: 5.9N minimum, 39.2N maximum.
Environmental Characteristics
Ambient temperature: -20°C to 80°C
Material:
Material：Copper
