Specification:

Condition: 100% Brand New
Item Type: Underwater Thruster
Material: Metal
Color: Black
Motor Outer Diameter: Approx. 50mm / 2in
Total Length of Thruster: Approx. 220mm / 8.7in
Fairing Outer Diameter: Approx. 121mm / 4.8in
Cable Length: Approx. Approx. 1m / 39.4in
Plug: 4.0mm / 0.2in Banana Head
Starting Voltage: 12V
Maximum Operating Voltage: 50V
Maximum Current: 25A
Maximum Thrust: 20kg
Maximum Power: 1200W
Applicable to: Applicable to ROV/AUV/Unmanned Vessel/Deep Water AUV

Test Data:
(1) The relationship between voltage and positive thrust: voltage V/thrust kg/current A;
12V: 2.1KG/3.4A;
14V: 2.6KG/4A;
16V: 3.1KG/4.7A;
22V: 5.3KG/7.6A;
24V: 6.2KG/8.9A;
30V: 9.7KG/12A;
40V: 14KG/17A;
48V: 18KG/22A;
50V: 20KG/24A

(2) The relationship between voltage and reverse thrust: voltage V/thrust kg/current A;
12V: 1.8KG/3.1A;
14V: 2.1KG/3.5A;
16V: 2.6KG/4.2A;
22V:4.8KG/7A;
24V: 5.3KG/7.6A;
30V: 8.0KG/11.6A;
40V:12.6KG/18A;
48V:16.3KG/22A;
50V: 16.8KG/21.7A

Package List:
1 x Thruster

Note:
1. The test data is for reference only, there may be some errors in actual.2. Please allow slight error due to manual measurement. Thanks for your understanding.3. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
