40 HP Right Angle Bevel Gearbox with Three 1" Keyed Shafts 1:1 19455-3SH-3KW-GR 1,800 Max RPM

SAR 859
Brand
Holdia
Weight
10.5 kg
– 1 +

Special Features

  • 【Part Number】Replace for 19455-3SH-3KW-GR 194553SH3KWGR
  • 【Specificities】The body is drilled and tapped 4-1/4" square with 3/8" holes.
  • 【Specificities】Gearbox is drilled and tapped with the same bolt pattern on both sides of the gearbox. This allows you to mount and arrange the shafts the way you need them. Input shaft turning clockwise will make one output shaft turn clockwise and the other turn counterclockwise (CW/CW/CCW).
  • 【Package Included】It's just like the picture.
  • 【1 Year Warranty】Please feel free to contact us for any questions, we will give quick response asap.

Description

Technical Information: Dimensions: 5-7/8" x 6-1/2" x 4-1/8" Bolt Pattern: 4-1/4" Square with 3/8" Tapped Holes Input Shaft: 1" X 2-1/4" with 1/4" Keyway Output Shaft: 1" X 2-1/4" with 1/4" Keyway (Both) Input Power: 40 HP Input Speed: 1,800 Max RPM Shaft Rotation: CW to CW/CCW with 1:1 Ratio
