Light Source

Source: 19*15W 4-IN-1 RGBW LEDs
Flicker free operation for broadcast TV and FILM
Life Span: 50000H
The life span may vary depending on several following factors but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control,and Dimming, etc)

Optics

19PCS Specific optic lens of highly efficient elements
Optimized light pipe for higher LED efficiency
10°-60°Smooth and quiet linear motorized zoom

Movement

PAN movement: 540°(8/16 bit)
PAN movement: 270°(8/16 bit)
Fast, quiet, smooth and precise 2-Phase motors
Smooth, fast and precise resolution for PAN/TILT movement with low noise operation
Scan position memory, auto reposition after unexpected movement
PAN/TILT reversible

Color System

Sophisticated 4 colors RGBW mixed
Even and soft light coverage with pure mixing
Preset color macros
Virtual color wheel for dynamic pattens with varibale speed
Preset random colors with variable speed

Control System

16/24 DMX channels USITT DMX-512
DMX512, master-slave, sound activated or auto operation
DMX recorder and edit function integrated
Shielded input signal protection for stable signal without interference
3-Pin XLR connectors IN/OUT

Display System

2.4" TFT LCD display
English/Chinese menu
4 Control buttons
DMX signal monitoring indicator
180°Reversible for LCD display
Display auto OFF

Power Supply

Electronic supply with active PFC
AC100-240V 50/60Hz
PowerCON IN with swtich and fuse
400W Power consumption

Weight

N.W.: 8.1kg
G.W.: 9.8kg

Dimensions

Product Dimensions: 188(D)*324.8(W)*395.4(H)mm
Packing Dimensions: 265(D)*490(W)*415(H)mm
