CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home in Saudi Arabia CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home in Saudi Arabia CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home in Saudi Arabia CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home in Saudi Arabia CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home in Saudi Arabia

CC2530 Wireless Module XL2530-232AP1 Core Board 2.4G Wireless Module Wireless Module Source Code WSN Wireless Sensor Network RF4CE Smart Home

SAR 25
Brand
JESSINIE
Category
Network Routers
Weight
6 g
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.
– 1 +

Special Features

  • XL2530-232AP1 is a data conversion device between serial port, which supports transparent transmission of serial port. With different level conversion boards, it can realize RS232, RS485 and USB interfaces
  • It can be used to easily realize the wireless serial port equipment, eliminate the trouble of wiring, save manpower, material and development time, make the product enter the market faster and enhance competitiveness
  • The network topology of the XL2530-AP1 is a mesh network structure. The router can realize the data relay function to expand the network coverage
  • The module is an industrial product with a frequency of 2405-2480MHz (16 RF channels). The baud rate of serial communication is up to 115200bps, and it supports transparent forwarding of serial data
  • The automatic networking equipment can be automatically networked after being powered on. If it is powered off and powered on again, it can realize self-repairing data transmission, and can carry out one-to-many, many-to-one and point-to-point transmission

Description

Product parameters:
Model: XL2530-232AP1
Interface: 1.27mm pin or SMT stamp hole interface
Serial interface: 3.3VTTL4
Serial baud rate: 2.4-115.2KBps
RF rate: 250KBps
Receiving current: 27mA
Emission current: 28mA
Channel: 16
Frequency range: 2405-2480MHZ
Output power: 2.5mW
Receiving sensitivity: -97dBm@250K
Module size: 21 * 26mm
Open land distance: 100m
Working temperature: - 25 ℃ -+75 ℃

Applications
industrial automation
Agricultural automation
Intelligent control of street lights
Remote data collection
Intelligent transportation system
Coal mine safety monitoring
Supermarket terminal
