Product Catalog: Power Relay
Package/Enclosure: Bulk
Type: High Current
Installation style: Through Hole
Contact Material: Silver Tin Oxide (AgSnO)
Contact form: SPST (1 Form A)
Contact Termination: Solder Pin
Relay Type: Universal
Coil Type: No Latch
Coil current: 16.7mA
Coil Voltage: 12VDC
Contact Shape: SPST-NO (1 Form A)
Rated contact (current): 10A
Switching voltage: 250VAC, 110VDC
Maximum On-Voltage (Max): 9.6 VDC
Shutdown Voltage (Min): 0.6 VDC
Working time: 20ms
Release time: 10ms
Features: Insulation
Type E Mounting Type: Through Hole
Terminal Type: PC
Pin Contact Material: Silver Tin Oxide (AgSnO)
Coil power: 200 mW
Coil resistance: 720
Ohm operating temperature: -40°C ~ 70°C
