Features:
Microprocessor based
0.25% Voltage Regulation Accuracy
0.5% accuracy up to 40% THD (harmonics associated with 6 SCR load)
63Vdc @ 7Adc PWM output
0-3X V/Hz limiting
Soft Start capability
20 standard stability selections and one customized selection
VAR/PF control
Over excitation limiting
Under excitation limiting
Voltage Matching
Manual Mode (Field current regulation)
Paralleling input from 1 or 5A CT secondaries
Nominal sensing inputs of 120, 240, 480 and 600Vac
Power Input from 50/60Hz shunt connections or PMGs operating at 50 to 400Hz
Five generator protection functions including Loss of Sensing transfer to manual
Alarm Contact Output
Accessory input LED Annunciation of operating conditions
Setup via PC using BESTCOMS software (included)
CE compliant
