Feature:

1. This has a wide range of functions. For example, it can be applied as the switches for the additional equipment inside and outside the vehicle.
2. For load under 5 Amp, you do not need a relay with this switch. For load above 5 Amps, we advise you to use of Automotive Relay
3. Easy setup. All you need is a 19mm hole and the switch will sit in nicely.
4. With waterproof rubber ring, have good performance at waterproof and dust-proof.
5. Universal fit all 12V Car SUV truck conversion Van RV Boat Yatch.

Specification:

1. Thread depth: 5/8" (16mm)
2. Head diameter: 7/8" (22mm)
3. Mounting hole size: 3/4" (19mm)
4. Depth inc contacts: 1.5" (38mm)
5. Switch combination: 1NO1NC
6. Operation types: Latching
7. Switch rating: 5A/250VAC, 5A/30VDC
8. LED rating: 15mA, AC/DC 12V

Package Include:

1 X Red LED Push Switch
1 X Plug
