18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia 18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia 18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia 18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia 18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia 18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit in Saudi Arabia

18pcs IR Infrared Obstacle Avoidance Sensor Module 3.3V-5V 3 Pin Reflective Photoelectric Sensor Module DIY Kit

Sorry, this product is not available
Brand
Shutao

Special Features

  • IR Infrared obstacle avoidance sensor module can be used for 3-5V DC power supply modules. It has red power indicator, connection : VCC-VCC; GND-GND; OUT-IO
  • The module detects an obstacle in front of the signal , the green indicator light on the board level , while low-level continuous output signal OUT port , the module detects the distance 2 ~ 30cm, detection angle 35 °, the distance can detect potential is adjusted clockwise adjustment potentiometer to detect the distance increases ; counterclockwise to adjust the potentiometer to reduce the detection distance .
  • The output port OUT sensor module can be directly connected to the microcontroller IO port, you can directly drive a 5V relay, using the comparator LM393
  • when detecting direction meet with obstacles (reflecting surface), reflected infrared receiving tube, after the comparator circuit processing, green indicator will light up, at the same time signal output interface to output digital signal (a low level signal).
  • IR Infrared obstacle avoidance sensor module can be widely used in robot obstacle avoidance, obstacle avoidance car, line count, and black and white line tracking and so on.

Description

The output port OUT sensor module can be directly connected to the microcontroller IO port , you can directly drive a 5V relay
The module detects the distance 2 ~ 30cm, detection angle 35 °, the distance can detect potential is adjusted
Can be used for 3-5V DC power supply modules
When the power is turned on, the red power indicator light
Can be applied for 3-5V DC power supply modules. When the power is turned on, the red power indicator light
Using the comparator LM393. Each module has been shipped threshold comparator voltage adjusted by potentiometer good, non-special case, do not adjustable potentiometer

Interface :
VCC: External 3.3V-5V voltage (can be directly connected to 5v MCU and 3.3v MCU)
GND: GND External
OUT: Small board digital output interfaces (0 and 1)
Connection : VCC-VCC; GND-GND; OUT-IO
With the screw holes of 3mm , easy fixed installation

Package include:
18 x Infrared obstacle avoidance module
