CMX Audio DA-240 Class D Power Amplifier, 240W, AC 115V to 230V/50-60Hz, Separate Speaker Outputs 8 Ohms/100V, Support 24V DC Operation, 1RU Height, Line Input with Separate Gain Control

Class-D power amplifier is used for public address class-d amplifier or commercial power amplifier, 240W RMS, support 100V & 8 Ohm, 1U height, 19 inch rack mount and 85% efficiency.

Key Features:
- Switching power technology digital power amplifier
- Class-D PA power amplifier of minimum power consumption
- 1RU height for less rack space and less heat generation
- One channel power amplifier into 19" rack mount unit
- Rated power output at 240W
- Separate speaker outputs 8Ω/100V
- Balanced line input by phoenix connector
- Line input with separate gain control
- Output with high-cut filter on/off
- Built-in auto standby feature on/off to save power consumption
- Separate indicators for protection, clip, input and output
- Complete short circuit, overload, high temp, clip and DC protection
- Wide AC input switchable between 115V and 230V
- Support 24V DC operation system

Specifications:
- Model: DA-240
- Rated Power Output: 240W
- Speaker Output: 100V & 8 Ohm
- Frequency Response: L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 70-10khZ ((+1/-3dB)
- Input: 0.775V, 0dBu, balanced phoenix connector by four channels
- Input Impedance: 10KΩ
- S/N Ratio: more than 80dB
- Crosstalk: More than 60dB, 1KHz, Max output
- Power Consumption: 300W
- Power Supply: AC 115V to 230V, 50-60Hz
- 24V DC: With
- Overall Dimensions: 19 x 16.5 x 1.73 inches
- Weight: 9.2 pounds
