Specification of OGRPHY 48V 105AH LiFePO4 Battery with 200A BMS
Features of OGRPHY LiFePO4 Battery
① Grade A Cells: OGRPHY LiFePO4 batteries are all made of grade A cell with UL certification.
② Longer Cycle Life: 20 times longer cycle life and 5 time longer float/calender life than lead acid battery, minimize replacement cost and reduce total cost of ownership.
③ Light Weight: About 40% of the weight of a comparable lead acid battery.
④ Deep Cycle: Can release twice power of lead acid battery.
⑤ Wide Temperature Range: -20℃ ~ 60℃
⑥ Superior Safey: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Electrical Characteristics
① Normal Voltage: 51.2V
② Normal Capacity: 105Ah
③ Cycle Life: >2000 cycles @0.5C 100%DOD, >5000 cycles @0.5C 80%DOD
④ Efficiency of Charge: 100% @0.5C
⑤ Efficiency of Discharge: 96 ~ 99% @0.5C
⑥ BMS Functions: Over charge, over discharge, over current, short circuit, Charge high temperature , Charge low temperature, discharge high temperature , Discharge low temperature protection, Bluetooth
⑦ Maximum Modules in Series: 1 pcs
Working Environmental
① Charge Temperature: 0 ℃ to 55 ℃ (32F to 131F)
② Discharge Temperature: -20 ℃ to 60 ℃ (-4F to 140F)
③ Storage Temperature: -10 ℃ to 45 ℃ (14F to 113F)
④ Waterproof IP Class: IP65
Proper way of charging and discharging will maximum your lithium battery's capacity and circle life. Pls refer to the product manual carefully before you using OGRPHY battery.
Thank you for choosing OGRPHY LiFePO4 battery!
"
