مميزات خاصة

High Performance CPU - Orange Pi 4 Pro 12G has 2×Cortex-A76 + 6×Cortex-A55, clocked at up to 2.0GHz, ensures smooth and efficient multitasking. Featuring an octa-core processor, a dedicated NPU, rich I/O, and extensive expansion capabilities—all integrated onto a compact board—the OPi 4 Pro handles demanding applications with ease.
Dedicated NPU - The 3 TOPS NPU accelerates real-time processing for tasks like face recognition and behavior detection. Supports INT8/INT16/FP16/BF16 multi-precision hybrid computing and is compatible with mainstream frameworks like TensorFlow, PyTorch, and ONNX, streamlining visual, speech, and inference tasks
GPU + RISC-V Co-Processor - Orange Pi 4 Pro 12GB Combines efficient graphics processing with real-time control capabilities for smarter system resource allocation and faster response times. Whether for robotics, smart gateways, industrial control systems, or complex AI inference tasks, it empowers you to bring your projects to life quickly and efficiently.
Wi-Fi 6+Bluetooth 5.4 - Faster, more stable transmission,even in high-interferenceenvironments. Gigabit Ethernet + PoE Support, Simplifies deployment bydelivering both power and dataover a single cable.
Open Software - Supports multiple operating systems including Android, Debian, Ubuntuand OpenHarmony. Comes with complete driver support and development toolchains, enabling rapid model migration, application development,and system customization.
Orange Pi Single Board Computers can builed a computer, a wireless server, Games, music and sounds, HD video, a speaker, Android, Scratch. Pretty much anything else, because Orange Pi is open source.

وصف

Hardware parameters

SoC: Allwinner A733
CPU: 2x Cortex-A76 Cores + 6x Cortex-A55 Cores, Max. Frequency 2.0GHz
GPU: Imagination BXM-4-64
NPU: 3 TOPS @ INT8, supports INT8/INT16/FP16/BF16 mixed precision
MCU: RISC-V E902 Co-processor (200MHz)
PMIC: AXP318
Memory:Supports up to 16GB LPDDR5

Storage:
Optional eMMC Module: 16GB/32GB/64GB/128GB
Optional SPI Flash: 128Mb or 256Mb
M.2 M-Key Slot (PCIe 3.0, supports NVMe SSD)
microSD Card Slot, supports up to 128GB

WiFi + Bluetooth: Integrated WiFi 6 & Bluetooth 5.4, supports BLE
Ethernet Transceive: Gigabit Ethernet (Onboard PHY: YT8531CA), supports PoE power

Display:
1x HDMI 2.0 port, supports up to 4K@60Hz
1x 4-lane MIPI DSI display interface

Camera:
1x 2-lane MIPI CSI camera interface
1x 4-lane MIPI CSI camera interface

USB:
1x USB 3.0 Host ports
3x USB 2.0 Host ports

Audio: 3.5mm headphone jack (supports input/output), single speaker, single microphone
Buttons: 1x BOOT button, 1x Reset button, 1x Power button
FAN: 2-pin 5V DC fan header
PCB size: 89x56mm
Weight: 58g
