[Easy to Install] The thermal pads come with protective films for simple application. just clean the surface, peel one side of the film, and place the pad between the heat source and the heat sink. the built-in viscosity ensures secure placement without the need for additional adhesives, making installation quick and hassle-free.
[Perfect Fit and Performance] With precise of 100x100x0.5mm and a thickness tolerance of ±0.01mm, these pads provide an optimal fit for various components. the soft and flexible material fills gaps effectively, ensuring maximum heat transfer and reducing thermal resistance for improved cooling performance.
[Versatile Application] Designed for various electronic devices including graphics cards, bridges, home appliances, high-speed hard drives, micro heat pipe radiators, and high-power power supplies. the thermal pad is also widely used in the led industry, offering reliable thermal management solutions for different heat-generating components.
[Durable and Reliable] Made from silicone material, these thermal pads offer excellent insulation with a mass resistivity of 10^12 and a breakdown voltage of 4.5kv. the pads are -retardant with a grade of 90v-0-1, ensuring safety and longevity even under extreme conditions.
[Excellent Thermal Conductivity] These silicone thermal pads provide outstanding heat transfer with a conductivity coefficient of 1.5w/m-k, efficiently dissipating heat from your cpu, gpu, and other electronic components. the material ensures across a wide temperature range from -50°c to 200°c, making it ideal for high-performance computing and demanding electronic applications.

وصف

1. Good thermal conductivity, insulation, viscosity, elasticity, low heat resistance, filling.
2. Applicable to graphics card bridge, home appliances, high-speed hard drive, micro heat pipe , high-power power supply, LED industry.
3. Thermally conductive silicone sheet has excellent thermal conductivity and meets the thermal insulation requirements of most electronic products.
4. The pad is specially designed for the use of heat transfer through the interval, which can fill the interval and effectively transfer the heat of the heat-generating component to the heat sink.
5. The pad has viscosity, simple and convenient application, stable heat conduction, insulation and softness and flexibility.
6. The pad is placed between the heater and the heat dissipating component to achieve heat transfer and insulation.

Spec:
Item Type:Thermal Conductive Pad
Size:100 x 100 x 0.5mm / 3.94 x 3.94 x 0.02in
Color:Blue
Thickness Tolerance:0.2+-0.01
Continuous Using Temperature:-50~200℃
Conductivity Coefficient:1.5W/m-k
mass resistivity:10^12
Breakdown voltage:4.5KV
Hardness:30±5 Shore A
proportion:2.05
tensile strength:15 kg/cm㎡
Extension:48%
Mystical/Fantasy Retardant Grade:90V-0-1
Users Manual:
1.Clean the surface, it will be glued or cleaned by the surface of the object to remove dust and oil.
2.Tear protective film
The left hand picks up the protective film on the side of the product with the right hand, and can not tear the protective film on both sides at the same time, reducing the number and area of direct contact with the silicone sheet to avoid damage to the viscosity and thermal conductivity of the product.
3.Fixed heat sink
Remove the protective film from the other side, apply a certain pressure to the heat sink after installation, and then fix it with screws.

Package List:
5 x Thermal Conductivity Pad
