NOTE:
Auxiliary power supply interface,with positive on the left and negative on the right.When the repaired battery pack voltage is below 40V,an external power supply is required.
2.54 mm pin,pins with the same serial number next to the pin represent the same node.When there are multiple plugs in the sampling cable of the protection board,they need to be alternately inserted in two rows in sequence
2.0mm pin,pins with the same serial number next to the pin represent the same node.When there are multiple plugs in the sampling cable of the protection board,they need to be alternately inserted on the two rows of pins in sequence.
Package Included:
JKBMS Adapter Board * 1
