Globe Valves
Actuator Mode : Without Manual And Instruction
Structure : Ball
Port Size : DN15(1/2"), DN20(3/4"), DN25(1"), DN32(1-1/4"), DN40(1-1/2"), DN50(2")
Media : Water
Material : Brass
Temperature of Media : Normal Temperature
Standard or Nonstandard : Standard
Pressure : Medium Pressure
Model Number : Motorized Ball Valve
Power Source : AC
Drive voltage : 220VAC 24VAC 24VDC 12VDC
Power : 6VA (only in the process of valve opening and closing)
Applicable medium : cold water, hot water or 50% glycol solution
Control method : three-wire two-control
Structure Forms : two-port
Open/Close Time : 5-15s
Valve body pressure : 1.6MPa
Applicable medium temperature : 0-95°C
Applicable ambient temperature : 0-65°C
Drive torque : 4-8 N.M
Shut-off pressure difference : 0.4Mpa
Lead length : 30 CM
Connection method : Female thread
