Filter Valves
DN6 G1/8 Thread 9mm
DN8 G1/4 Thread 12mm
DN10 G3/8 Thread 15mm
DN15 G1/2 Thread 19mm
DN20 G3/4 Thread 25mm
DN25 G1 Thread 31mm
DN35 G1-1/4 Thread 38.5mm
DN40 G1-1/2 Thread 45mm
Service voltage : AC220V AC110V AC24V DC24V DC12V ( allow ± 10% )
Operating: Direct acting
Body Materia:l Brass
Working pressure: ( water, air ) : 0~10 kgf/cm2; ( oil ) : 0~7 kgf/m2;
Structure : Regulating
Port Size : 1/4",1/8",3/8",1/2",3/4",1",2",
Media : Water
Material : BRASS
Temperature of Media : Medium Temperature
Power : Solenoid
Standard or Nonstandard : Standard
Pressure : Medium Pressure
Model Number : 2W
Power Source : AC
