Globe Valves
Specification
Applicable medium: cold, hot water or 50% glycol solution
material: Brass,flame-retardant PC material
Control method: three wire two control
Way: two way/three way (three way is T type)
Driving voltage: AC220V, DC24V, DC12V, 50/60Hz
Power: 6W (only when the valve is opened and closed)
Drive torque: 6 N.M
Play time: 6-15 S
Nominal pressure: 1.6MPa
Applicable medium temperature: 0-95
Applicable ambient temperature: 0-65
Lead length: 30 CM
Connection method: G internal thread
Notice:
1. The more you order, the more offers, please contact us
2. Package list: Valve*1
==========
Structure : Ball
Port Size : DN15(1/2"),DN20(3/4"),DN25(1"),DN32(1-1/4"),DN40(1-1/2"),DN50(2")
Media : Water
Material : Brass
Temperature of Media : Normal Temperature
Standard or Nonstandard : Standard
Power Source : AC
