Globe Valves
Product information
Medium: Cold water, Hot water or 50% Glycol solution
Body material: Brass
Wiring mode: Three-Wire two-control Three-Wire one-control
Structure Forms: Two Ways
Driving voltage: 220VAC, 24VAC, 24VDC, 12VDC
Power consumption: 6 W (only when the valve is opened and closed)
Applicable medium temperature: 0-95
Action time: 5-15 S
Nominal Pressure: 1.6 Mpa
Lead length: 30 CM
Connection method: G Female thread
Notice:
1. The more you order, the more offers, please contact us
2. Package list: Valve*1
1.SW is connected to the OPEN, the valve is open, internal automaticpower off after in place, the valve remain fully open position.
2.SW is connected to the CLOSE, the valve is closed, internal automaticpower off after in place, the valve remains fully closed position.
==========
NC or NO : Normally Closed
Actuator Mode : Without Manual And Instruction
Structure : Ball
Port Size : 2"(DN50)
Media : Water
Material : Brass
Temperature of Media : Normal Temperature
Power : Electric
Standard or Nonstandard : Standard
Pressure : Medium Pressure
Power Source : AC
voltage : 220VAC 24VAC 24VDC 12VDC
