Sargent 32 Electric Mortise Lock, Bright Stainless Steel, E Rail for 24 inches
Special Features
Standard door thickness: 1-3/4" (44mm). Specify thickness and panels for thicker doors
Fixed backset: 2-3/4" (70mm)
Case material: 12-gauge heavy-duty wrought steel, zinc dichromate plated. Thickness: 7/64" (3mm) (.109")
Adjustable front plate: Brass, bronze, or stainless steel. Size: 8" x 1-1/4". ANSI Standard A115.1. Angle adjustment: flat to beveled 1/8" in 2" increments
Spring material: High carbon steel
Knob hubs: Sintered iron copper infiltrated
Lever hubs: Cold forged steel
Institutional hubs: Stainless steel (3- prefix)
Latchbolt: Stainless steel, 3/4" projection. Anti-friction, reversible
Auxiliary deadlatch: Stainless steel, non-handed
Deadbolt: Hardened stainless steel, 1" projection
Hand configuration: Specify on order. Field reversible (default RH)
Strike: Brass, bronze, or stainless steel. ANSI Standard A115.1. Curved lip, non-handed. Strike box optional
Keys: Two nickel silver keys (control or emergency key required)
Cylinder: Brass, size #41 (1-1/8") standard. Compatible with SARGENT Signature, V-10, XC, and KESO Security Systems
Description
Sargent's 60RX-8270-24V LW1E 32, an Electric Mortise Lock in Bright Stainless Steel.
