Operational Grade 1 Certified: ANSI/BHMA A156.13, Series 1000
Fire Resistance: UL/cUL Rated Up to 3 Hours
Windstorm Compliance: Certified, Check Local Codes
Durable Mechanism: Stainless Steel
Backset Measurement: 2-3/4"
Latchbolt Throw: 3/4" Stainless Steel
Door Thickness: Standard 1-3/4", Up to 3-1/4" Thick Doors Available
Front Design: Bevel Front, Adjustable from Flat to Standard Bevel
Cylinder Details: Brass, 6-Pin, Keyed-Random with Two Standard Keys, 7-Pin Available
Handing Reversibility: Field Reversible
Strike Lip: 1-1/4" Curved for 1-3/4" Door, Special Orders Available, All Reversible
Finish Options: 17 Available Finishes
Warranty Coverage: 10 Year Mechanical
Description
This Yale 8800 Series Mortise Lock Trim Pack, designed for commercial use, ensures robust durability and security. It features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification. Installation is simplified with quick lever handing, field reversible latchbolt, and standard nonhanded strike. Available in Satin Chrome finish for Mortise Hotel/Motel applications, it's compatible with various cylinder and turn combinations (09, 22, 32, 40, 47, 60, 61 & 67).
