Fiber Optic Products
Please note:
1. Default with 1pcs1310nm A side SFP module and 1pcs 1550nmB side, 2pcs 1550nm B Side or 2pcs 1310nm A sidecan be provided as request.
2.Please leave us a message about which your switch is compatible. We Will send compatible SFP modules as your request.
Features:
Operating data rate up to 10.3Gbps
850nm VCESL Transmitter
Distance up to 300m @50 / 125 um MMF
Single 3. 3V Power supply and TTL Logic Interface
Duplex LC Connector Interface, Pluggable
Compliant with SFP+ Specification SFF-8431
Compliant with 10G 1200-M5-SN-I and 1200-M6-SN-I FC standard
Compliant with 8.5G 800-M5-SN-I and 800-M6-SN-I FC standard
Compliant with 4.25G 400-M5-SN-I and 400-M6-SN-I FC standard
Compliant with 2.125G 200-M5-SN-I and 200-M6-SN-I FC standard
Compliant with 1.0625G 100-M5-SN-I and 100-M6-SN-I FC standard
Compliant with IEEE 802.3ae 10GBASE-SR/SW
Operating Case Temperature Standard:0degC~+70degC
Applications:
10GBASE-SR at 9.953Gbps
10GBASE-SW at 10.3125Gbps
1000Base-SX Ethernet
8x FC at 8.5Gbps
4x FC at 4.25Gpbs
2x FC at 2.125Gpbs
1x FC at 1.0625Gbps
==========
Size : 30*12*3
Fiber Type : Single Mode
Connector Type : LC/UPC
Item Length : 30M
Model Number : 10G-LC
