Operational Grade 1 Certified: ANSI/BHMA A156.13, Series 1000
Fire Resistance: UL/cUL Rated Up to 3 Hours
Windstorm Compliance: Certified, Check Local Codes
Mechanism: Stainless Steel Construction
Backset Measurement: 2-3/4"
Latchbolt: 3/4" Stainless Steel Throw
Door Thickness: 1-3/4" Standard, Up to 3-1/4" on Order
Front Design: Bevel Front, Adjustable from Flat to Standard Bevel
Cylinders: Brass, 6-Pin, Keyed-Random with Two Keys, 7-Pin Available
Handing: Field Reversible
Strike Options: 1-1/4" Curved Lip Standard, Special Order Available, All Reversible
Finish Variety: 17 Finishes Available
Warranty Coverage: 10 Year Mechanical
وصف
Yale's 8800 Series Mortise Locks, designed for robust, long-lasting performance in commercial settings, feature a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification. Installation is simplified with quick lever handing, field reversible latchbolt, and standard nonhanded strike. This lock pack, suitable for Mortise Asylum or Institutional use with Cylinder x Cylinder configurations, comes with VIR Trim in Bright Chrome finish.
