187 - Series Thermal Circuit Breakers - Surface Mount

60 Amp Circuit Breaker

PN: 7140

Features:

Combines switching and circuit protection into a single device

All components meet SAE J1171 external ignition protection requirements

Clear, single lever operation

"Trip Free" design cannot be held "ON" during fault current condition

Waterproof

Recessed mounting holes for clean appearance

Large clearance around terminal studs accept heavy gauge wire lugs

Robust 5/16 terminals provide high torque connections

Large lever with vertical/horizontal orientation provides indication of trip status

Ignition protected - safe for installation aboard gasoline powered boats

Specifications Circuit Breaker Class:Type III - Switchable / Manual Reset - Trip FreeType:Thermally Responsive Bi-Metal BladeCase Material:Thermoset PolyesterVoltage Rating:48 Volts DC MaximumInterrupt Rating:5,000 Amperes
