Products Description
Product Paramenters
Laser light source
Laser diode 650nm, 1mW; complies with GB7247.1-2001, Class I laser eye safety requirements
Laser Class
Class 1
Ranging frequency
1000Hz(Adjustable)
Working distance
5m
10% reflectivity
1m
Response time
lms(Adjustable)
Systematic Error
±10mm
Continuous Error
±3mm
Operating voltage
9-36V
interface
NPN/PNP/RS485/4-20mA
Power consumption
0.5W
weight
Dimensions (length, width, height)
41mm x37mm x22mm
Protection level
IP65
Operating temperature
-20C-+75
Storage temperature
-40C-+100
Ambient light resistance
>50klux
Product Dimensions
Product Wiring Diagram
PRODUCT APPLICATION
==========
High-concerned chemical : None
is_customized : Yes
Theory : Optical Sensor
Material : Metal
Type : Optical-Electronics Sensor
Output : Switching Transducer
Origin : Mainland China
Use : Position Sensor
Product Name : Distance Measurement Laser
Protection Level : IP65/IP67
Supply Voltage : 9-36V
Temperature : -20C-+75
Certificate : CE,Rohs, ISO9001
