✅【Motor parameters】Model:130ST-M10025, Rated power:3.8kw, Rated voltage:220v, Rated current:10A, Rated torque:10N.m, Peak torque:25N.m, Back EMF:70V/KRPM, Torque coefficent:1.0N.m/A, Rotor inertia:1.94x10(-3), Winding resistance:1.29, Winding inclucfance:5.07mH, Elecfrical time constant:3.93ms, Rated speed:2500rpm, Motor insulation: class B, Protection class:IP65, Operation temperature:-20-+50 degree.
✅【Stable performance,】By adopting unique signal processing technology, the accuracy of the encoder has been substantially improved, which can provide more accurate feedback information, thus improving the control accuracy and stability of the system.
✅【High load】Built-in using high-quality pure copper coil, constant torque, the motor is close to 99% torque continuous output; high load, can be triple overload motor, strong overload resistance, stable performance, servo motor speed can be controlled. Precise position to receive signals fast, the same size of the load accelerated to the same speed in a shorter time.
✅【High precision】There are high-precision position and speed control capability, can meet the requirements of precision machining and positioning, but also according to the requirements of the system speed and acceleration control, can meet the requirements of a variety of machinery and equipment, in many areas to be widely used.
✅【Application Areas】Suitable for a variety of automation equipment and instruments, such as screw machines, automatic equipment, medical equipment, semiconductor equipment, engraving equipment, measuring equipment, AGV carts, etc.
