Globe Valves
APR port: 1/4" female thread (ID12mm)
P port: input port,
A. Port: Output port
R. port: port

NC (normally closed)

When the valve is powered off,

P port A port, closed

A port R port, opened

When the valve is energized,

P port A port, opened

A port R port, closed

Operating pressure: about 1.47~7.84 bar

Can't work without air pressure

Fluid type:
air, gas
Operating mode:
NC, normally closed
Inlet = Outlet port size:
4mm, 6mm, 8mm
10mm, 12mm
Coil voltage:
DC: 12V, 24V, 36V
AC power: 110V, 220V
Solenoid valve type:
3 port 2 location
(3 ways 2 locations)
Operating pressure:
1.5 - 8 kgf/cm^2
Pressure resistance:
1.5Mpa
Protect:
IP65
temperature:
5-50℃
Body material:
Aluminum alloy
Package Contents:
1 PC solenoid valve
2 piece set of quick connectors
1 piece muffler

application:

* Control proper flow and direction.

* Electrically driven pneumatic power control.
