Part Number: DSV-080-34T DSV-080 34T-N

Specification:
Pressure Max psi: 3000
Pressure Max bar: 207
Flow gpm: 3.0
Flow lpm: 11.4
Cavity: 080-4
Coil:Series 8 K-Coils (External Frame), Series 8 S-Coils (Internal Frame)
Valve Style: Spool
Operating Pressure: 3000 PSI (207 Bar)
Flow: Nominal flow 3 gpm (11.4 L/min.)
Internal Leakage: (Per land) 10 in3/min (164 cc/min) max. at 3000 PSI (207 Bar)
Temperature: -30°F to +250°F (-35°C to +120°C)
Coil Duty Rating: Continuous from 85% to 110% of rated voltage.
Current Draw: 12 VDC is 1.3 amps.
Minimum Pull-In Voltage: 85% of rated voltage at 3000 PSI (207 Bar)
Recommended Filtration: ISO 17/15/13
In-Line Body Material: Anodized 6061T6 aluminum alloy rated at 3000 PSI (207 Bar)
