Thermowells
K type Specifications:
Model: WRN-010 Type: K Material:Cr-Ni,Si-Ni Measuring Temperature: 0°F-2372°F (0°C-1300°C) Total Length: 215mm(8.5") / 315mm(12.5") 515mm(20.5") Insulator: Two-Hole Insulator Probe diameter: 8mm Probe length: 200mm/300mm/500mm
PT100 type Specifications:
Model: WZP-010 Type : PT100 Measuring Temperature: 0°F-1112°F (0°C-600°C) Total Length: 215mm(8.5") / 315mm(12.5") 515mm(20.5") Insulator: Three-Hole Insulator Probe diameter: 8mm Probe length: 200mm/300mm/500mm
The default Wire diameter is 2mm
Mark:Length is from 225mm to 525mm
