JXK-10 Current Transducer Current Measurement Transmitter Segregated Hall Effect Current Sensor DC0-600A Current Transmitter
Introduction
. Working principle: open loop direct measurement.
.Usage: Used for measuring DC, AC, pulse current and other arbitrary waveform current.
. Advantages: Better cost performance, low power consumption, small volume, light weight, easy installation, perforation input and no insertion loss.
. Application: Frequency conversion speed control system, electric welding machine, electrochemistry, power supply monitoring, electric locomotive, low level starting protection.
.The input, output, power and outer shell are isolated, with strong anti-interference ability and high reliability.
.Full channel configuration,Parameter customizable.
==========
Battery Included : No
High-concerned chemical : None
Dimensions : 22mm
Operating Temperature : -10~+70 Celsius
Supply Voltage : DC12V,DC24V,DC15V
Accuracy Class : 0.5%
Model Number : JXK-10
Display Type : Analog Only
DIY Supplies : Electrical
Certification : ,FCC,
1 : ac current transmitter
2 : dc current transmitter
3 : ac/dc current transmitter
4 : current transmitter
5 : 4-20ma current sensor
6 : dc current sensor 4-20ma
7 : current transmitter dc
8 : current transducer 4 20ma
9 : dc current transducer
10 : ac current transmitter
11 : ac dc current transmitter
12 : current transducer 0 to 10v
13 : ac current transducer
14 : 0-10v current transmitter
15 : 0-5v current transmitter
16 : 4-20ma ac current transmitter
17 : 4-20ma current transmitter
18 : ac current transmitter rs485
