Radio Frequency Attenuators
Applications: DC-18GHz, SMA male to female 10W coaxial fixed attenuator
Technical Specifications:
Normal impedance: 50 ohms
Frequency range: DC to 6GHz/8GHz/12GHz/18.0GHz (optional)
The VSWR (Standing Wave Ratio) is 1.35 in the 18GHz band and 1.2 in the 6GHz band.
Rated power: 10 watts
Attenuation values: 3, 5.6, 10, 15, 20, 30, 40 dB selectable.
