Isolation
Filament voltage
Voltage: 10V
If: 3.25 A
Maximum Ratings
Anode voltage: 1250V
Anode power dissipation: 75 W
Maximum signal output power: 150 W
Maximum anode current: 120 mA
Interelectrode capacitance
Input capacitance: 6PF
Output capacitance: 4.5 pF
Grid capacitance: 14.5 PF
Static parameters
Voltage: 1250V
Voltage: -200V
Current: 80 mA
Transconductance: 3mA/V
Richter temperature: 1.7 K
µ: 5
RL: 3.4 K
Peak voltage (Ug): 69 V
Output power: 15W
