Sensors
Number of Beams
22/24/26/28Pairs
Beams Spacing
20mm
Protection Height
420/460/500/540mm
Detection Distance
3m as default, can dustomize 5m, 10mz 15m, 20m
Working Voltage
DC/12-24V
Power Consumption
15W
Output
NPN+PNP
Response Time
Housing Material
Aluminum Alloy (yellow)
Detection Method
Through beam
Ambient Temperature
Insulation Resistance
>100MQ
Anti-in terferance
WOOOLux (Angle of incidences 5°)
Connection
M12 connector cable (3 pins with 2 wire)
M12 connector cable (4 pins with 4 wire)
Protection
Reverse connection Protection/ Output short circuit protection
Dielectric Strength
AC1500C.60S
Applicable Temperature
-10°C-55°C
Section Size
35*50mm
MODEL
NUMBER OF BEAMS
SPACING
PROTECT HEIGHT
UPPER COVER HEIGHT
BLIND ZONE
DOWN COVER HEIGHT
TOTAL HEIGHT
D(mm)
H(mm)
A1(mm)
B1(mm)
B2(mm)
A2(mm)
G(mm)
APS50-0420NB
4 20
60
20
10
25
20
140
APS50-0620NB
6 20
100
20
10
25
20
180
APS50-0820NB
8 20
140
20
10
25
20
220
APS50-1020NB
10
20
180
20
10
25
20
260
APS50-1220NB
12
20
220
20
10
25
20
300
APS50-1420NB
14
20
260
20
10
25
20
340
APS50-1620NB
16
20
300
20
10
25
20
380
APS50-1820NB
18
20
340
20
10
25
20
420
APS50-2020NB
20
20
380
20
10
25
20
460
APS50-2220NB
22
20
420
20
10
25
20
500
APS50-2420NB
24
20
460
20
10
25
20
540
APS50-2620NB
26
20
500
20
10
25
20
580
APS50-2820NB
28
20
540
20
10
25
20
620
APS50-3020NB
30
20
580
20
10
25
20
660
APS50-3220NB
32
20
620
20
10
25
20
700
==========
Material : Aluminium alloy
Switch Type : Switch
Model Number : APS50-2220 APS50-2420 APS50-2620 APS50-2820
Item Type : SWITCHES
Beams Spacing : 20MM
Cable length : 2.8 meter
Number of beams : 22/24/26/28
Detection Distance : 3/5/10/15/20M
Protection Height : 420/460/500/540
model1 : APS50-2220
model2 : APS50-2420
model3 : APS50-2620
model4 : APS50-2820
Section Size : 35*50MM
